◆功率Rated Power AES 550W
◆峰值功率Peak Power 1200W
◆阻抗Nominal Impedance 8Ω
◆频率响应Frequency Response50Hz—18kHz
◆灵敏度Sensitivity(2.83V/1m)102dB
◆最大控制声压Maximum Spl Continuous 131dB
◆峰值声压Maximum Spl Peak 134dB
◆覆盖角度Dispersion 水平Horizonta10/100 垂直Vertical 55
◆驱动器规格Drive Specification
◆低音Lf Drive 1×15"(390mm)voice Coil
◆高音Hf Drive 2"exit Compression Driver 3" voice Coil
◆接线器Connectors 3×Neutrik Nl4
◆接线方式Paralleled Neutnik Speakon＋2/-2, ＋2/-2HF,+1/-1LF
◆箱体原料Enclosure Material Plywood
◆箱体面漆Cabinet Finish Textured Black Polyester Paint
◆吊挂装置Hoisting Set Textured Polvester Points
◆箱体尺寸Dimensions(w×h×d)434×675×368
◆重量Weight(Kg)29Kg
